Detector Mount
- Model SX-14000
- Model SX-14001
- Model SX-14002 (Waveguide Antenna Trainer Kit)
- Model SX-14003
- Model SX-14004
Detector Mount
Detector Mount are used detect the low frequency signals with the help of the IN23 detector diode. The Detector Diode is mounted on the broad wall of the waveguide. A shorting plunger is used to tune the max power near the detector diode
Specifications
| Model |
Band |
Freq. Range(GHz) |
Waveguide | O/P Connector | Crystal Diode |
|---|---|---|---|---|---|
| SD-124 | S | 2.60-3.95 | WR-284 | BNC(F) | IN21 |
| CD-124 | C | 3.95-5.85 | WR-229 | BNC(F) | IN21 |
| JD-124 | J | 5.85-8.20 | WR-137 | BNC(F) | IN23 |
| XD-124 | X | 8.20-12.40 | WR-90 | BNC(F) | IN23 |
| KuD-124 | Ku | 12.40-18.00 | WR-62 | BNC(F) | IN23 |
| KD-124 | K | 18.00-26.50 | WR-42 | BNC(F) | IN23 |
